Pearson Prentice Hall™ is a trademark of Pearson Education, Inc. Pearson® is a registered trademark of Pearson plc Prentice Hall® is a registered trademark of Pearson Education, Inc.
Digital fundamentals 10th edition manual#
Instructors of classes using Floyd, Digital Fundamentals, Tenth Edition, may reproduce material from the instructor’s manual for classroom use. #Digital fundamentals 10th edition chapter 8 manual
2 CHAPTER 2 Number Systems, Operations, and Codes.
23 CHAPTER 4 Boolean Algebra and Logic Simplification.35 CHAPTER 5 Combinational Logic Analysis.60 CHAPTER 6 Functions of Combinational Logic.95 CHAPTER 7 Latches, Flip-Flops, and Timers.115 CHAPTER 8 Counters. 175 CHAPTER 11 Programmable Logic and Software. 185 CHAPTER 12 Signal Interfacing and Processing. 239 PART 4: LABORATORY SOLUTIONS FOR EXPERIMENTS IN DIGITAL FUNDAMENTALS by David Buchla.265 210 PART 2: SYSTEM APPLICATION ACTIVITY SOLUTIONS.Ģ04 CHAPTER 14 Integrated Circuit Technologies. To access supplementary materials online, instructors need to request an instructor access code. Go to where you can register for an access code. Within 48 hours after registering you will receive a confirming e-mail including an instructor access code.
Digital fundamentals 10th edition full#
Once you have received your code, go the site and log on for full instructions on downloading the materials you wish to use. #Digital fundamentals 10th edition chapter 8 full
Digital fundamentals 10th edition password#
NOTE: For access to hidden faults in Multisim circuits, the password is book.ĬHAPTER 1 INTRODUCTORY CONCEPTS Section 1-1 Digital and Analog Quantities 1.ĭigital data can be transmitted and stored more efficiently and reliably than analog data. #Digital fundamentals 10th edition chapter 8 password Also, digital circuits are simpler to implement and there is a greater immunity to noisy environments.Ī clock, a thermometer, and a speedometer can have either an analog or a digital output. Section 1-2 Binary Digits, Logic Levels, and Digital Waveforms 4. In negative logic, a 1 is represented by a LOW level, and a 0 by a HIGH level.Ī 1 is a HIGH and a 0 is a LOW: (a) HIGH, LOW, HIGH, HIGH, HIGH, LOW, HIGH (b) HIGH, HIGH, HIGH, LOW, HIGH, LOW, LOW, HIGH In positive logic, a 1 is represented by a HIGH level and a 0 by a LOW level. The waveform in Figure 1-61 is periodic because it repeats at a fixed interval.
Digital fundamentals 10th edition serial#
TW = 2 ms T = 4 ms ⎛t ⎞ ⎛ 2 ms ⎞ % duty cycle = ⎜ W ⎟100 = ⎜ ⎟ 100 = 50% ⎝T ⎠ ⎝ 4 ms ⎠Įach bit time = 1 μs Serial transfer time = (8 bits)(1 μs/bit) = 8 μs Parallel transfer time = 1 bit time = 1 μsĪn AND gate produces a HIGH output only when all of its inputs are HIGH.Īn OR gate produces a HIGH output when either or both inputs are HIGH. #Digital fundamentals 10th edition chapter 8 serial
Section 1-4 Introduction to the System Concept 19.Ĭhapter 1 1 = 100 μs 10 kHz 100 ms Pulses counted = 1000 100 μs An exclusive-OR gate produces a HIGH if one input is HIGH and the other LOW. Section 1-5 Fixed-Function Integrated Circuits 22.Ĭircuits with complexities of from 100 to 10,000 equivalent gates are classified as large scale integration (LSI). The pins of an SMT are soldered to the pads on the surface of a pc board, whereas the pins of a DIP feed through and are soldered to the opposite side. Pin spacing on SMTs is less than on DIPs and therefore SMT packages are physically smaller and require less surface area on a pc board.Ĭhapter 1 Section 1-6 Test and Measurement Instruments 25.Īmplitude = top of pulse minus base line V=8V−1V=7VĪ flashing probe lamp indicates a continuous sequence of pulses (pulse train). The following do not describe PLDs: VHDL, AHDL Section 1-7 Introduction to Programmable Logic 27. SPLD: Simple Programmable Logic Device CPLD: Complex Programmable Logic Device HDL: Hardware Description Language FPGA: Field-Programmable Gate Array GAL: Generic Array Logicĭesign entry: The step in a programmable logic design flow where a description of the circuit is entered in either schematic (graphic) form or in text form using an HDL.
Digital fundamentals 10th edition software#
Simulation: The step in a design flow where the entered design is simulated based on defined input waveforms.Ĭompilation: A program process that controls the design flow process and translates a design source code to object code for testing and downloading.ĭownload: The process in which the design is transferred from software to hardware. #Digital fundamentals 10th edition chapter 8 software
